(MSS-R-BU42 / BU721 / BU2391) Auto Focus OnlineTemperature Measurement Thermal Camera

Commodity name： (MSS-R-BU42 / BU721 / BU2391) Auto Focus OnlineTemperature Measurement Thermal Camera

Category:

Email:

Description

Welcome to Shanghai Mengsheng Sheng International Trade

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

▍Temperature Visualization
Fuguang electric focusing lens series thermal cameras, equipped with professional electric focusing lenses, provide clear images. Its 1.3 million pixels can present high-quality and delicate images, which are widely used in industrial automation, machine vision, education and scientific research, and other fields.

▍Product Strengths
• Electric Focusing, Multiple Lenses Available
• Multiple electronic focusing lenses, wide depth-of-field imaging
• Up to 50Hz image frame rate
• Support gigabit network data transmission
• Lens position is saved when power is off
• Combination of Software and Hardware, Multi-scenario Application
• Support standard protocols such as RTSP/ONVIF/Pelco
• Professional infrared analysis software, ROI area temperature measurement analysis, alarm linkage
• Provide SDK to support and assist the secondary development
• Megapixel Thermal Camera, Ultimate Visual Experience
• Up to 1280×1024 resolution
• High thermal sensitivity of 50mK
• Minimum spatial resolution of 0.34mrad
• Small size, low power consumption, easy to install

Array Size	384×288 Lens Conﬁguration Table
Focal Length (mm)	7.8	13	15	19	25
FOV (Horizontal×Vertical)	47°×35.6°	29.6°×22°	25°×18.7°	19.6°×14.7	14.8°×11.1°
IFOV	2.17mrad	1.3mrad	1.1mrad	0.89mrad	0.68mrad
Array Size	640×512 Lens Conﬁguration Table
Focal Length (mm)	7.8	13	15	17	19	25
FOV (Horizontal×Vertical)	54.3°×44°	33.7°×27°	29.4°×23.5°	25.2°×20.3°	22.8°×18.4°	17.6°×14.1°
IFOV	1.54mrad	0.92mrad	0.80mrad	0.706mrad	0.63mrad	0.48mrad

▍Specifications

Model		BU42	BU72Q	BU2391
Thermal Imaging Parameters	Detector Type	Uncooled VOx Infrared Focal Plane Detector
	Resolution	384×288	640×512	1280×1024
	Pixel Pitch	17μm	12μm	12μm
	Image Frequency	50Hz	25Hz	15Hz
	Spectral Band	8μm~14μm
	NETD	<50mK
	Palettes	Black-hot/white-hot, 18 palettes are available
	Digital Zoom	1.0~8.0 continuous zoom (step size: 0.1)
	Mirroring	Horizontal/Vertical/Diagonal, supporting selection of ROI
	Focusing	Electric Focusing
Temperature Measurement Function	Measurement Range	-20℃~+150℃; 0℃~550℃
	Measurement Accuracy	±2ºC or ±2% of the reading (The greater shall prevail)
	Automatic Gain Mode Switching	Supported
	Temperature Data	Synchronous transmission of temperature data and image data
	Temperature Measurement Correction	Support modiﬁcation of environmental parameters
	Temperature Analysis	Any ﬁxed point; full-screen max./min. temperature capture; center point; line/area analysis tool; manually choose temperature width
	Temperature Width Stretch	Support temperature width stretch
	Thermal Image Capture	Support thermal image capture and secondary analysis
Network Function	Network Protocol	TCP, UDP, ICMP, DHCP, RTSP		TCP, UDP, ICMP, DHCP
	Interface Protocol	ONVIF		GigE Vision
	Ethernet	Control and imaging
System Interface	Communication Interface	1 RJ45 (support gigabit network, IEEE 802.3 standard)
		1-channel RS485 interface, supporting PELCO-D PTZ control protocol expansion
	Alarm Interface	1-channel alarm input, 1-channel alarm output
	Video Interface	1-channel analog video		⸺
Image Transmission	Video Compression Standard	H.264/H.265		⸺
Power Supply	Power Supply	Support PoE power supply and DC power supply
	Voltage	10~36V DC		6~16V DC
	Power Protection	Support over-voltage, under-voltage, and reverse connection protection
General Speciﬁcations	Operating Environment	-20°C～+60°C; <95% RH
	Typical Power Consumption @25°C	≤3W	≤3.3W	≤4.5W
	Dimensions	70×63×143(mm)
	Weight	＜430g（without adapter bracket）		＜725g
	Authentication	CE/FCC/RoHS
	Shock	30g, 11ms, all axes
	Vibration	4.3g, random vibration, all axes
	Product List	Thermal camera, adapter bracket, power adapter, power cord, gigabit network cable		Thermal camera, gigabit network cable, power cord, power adapter

▍Applications

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
