(MSS-R-Q311) Pocket Thermal Camera

Commodity name： (MSS-R-Q311) Pocket Thermal Camera

Category:

Email:

Description

Welcome to Shanghai Mengsheng Sheng International Trade

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

▍Rotate to Unlock Your Thermal Potential
Tianquan pocket thermal camera Q311, equipped with a 256×192 high-performance infrared detector, rotating lens design, and a 56° large FOV, which can meet special space inspection requirements. It is an ideal choice for operation and maintenance engineers, HVAC engineers, and equipment inspectors.

▍Product Strengths
• Rotating Lens, Smart Design
• The lens supports 0°-90° rotation, 56° large FOV, and efficient investigation.
• Equipped with a gravity-sensing UI interface, which can be switched freely according to usage conditions
• Clear Thermal Images, Easy for Operation
• Equipped with self-developed 256×192 uncooled infrared detector
• The temperature measurement range is as high as 550°C, meeting the requirements for monitoring more targets
• 2-megapixel visible light lens, supporting 4 image modes to improve investigation efficiency
• Smart Connection, Powerful Functions
• Support TAS analysis software, displaying the temperature of points, lines, and areas directly
• Support USB plug-and-play analysis, flexible alarm threshold setting, and multi-area real-time alarm on one screen

▍Specifications

Model		Q311
Thermal Imaging Parameters	Detector Type	Uncooled infrared detector
	Detector Resolution	256×192
	Pixel Pitch	12μm
	NETD	40mK
	IFOV	3.8mrad
	Frame Rate	25Hz
	Minimum Imaging Distance	0.3m*
	FOV	56°×42°
	Focal Length	3.2mm
	Focusing Mode	Focus-free
	Measurement Range	-20°C~+150°C, 100°C~550°C
	Measurement Accuracy	±2℃ or ±2% of the reading, whichever is greater
Camera Functions	Measurement Unit	Celsius, Fahrenheit, Kelvin
	Measurement Resolution	0.1℃
	Temperature Measurement Function	Central point temperature measurement, highest/lowest-temperature tracking
	Temperature Analysis	Customized analysis on the measured temperature of 10 dots/10 lines/10 areas
	Image Mode	Infrared/Visible light/PIP/Dual-spectrum fusion
	Palette	Black-hot, white-hot, iron red, lava, rainbow, high-contrast rainbow, black red
	Temperature Alarm	Highest/Lowest temperature alarm in full frame area
	Alarm Type	Image alarm
	Auto Snapshot at Alarm	Support auto snapshot at alarm time. Photo number and time interval are settable
	Timed Photographing	Supported. Number of photos and time interval are settable
	Photo Storage	Image and temperature data can be saved
	Secondary analysis	Equipped with analysis software for PC to conduct secondary analysis on data
	Image Note Function	Voice annotation
	Image Naming	Support automatic naming/text input/naming through QR code scanning
	Digital Zoom	1× 2× 4×
	Visible light	2MP
	Screen	3.5-inch touch screen
	Fill-in Light	Supported
	Video Transmission	Support USB real-time video preview and temperature analysis
Others	Charging Indicator	Supported
	Storage	Internal 16GB memory card
	Battery Life	About 6h
	Charging Time	About 3h
	Charging Voltage	DC 5V
	Power Interface	USB Type-C
	Tripod Socket	Supported
	Drop Protection	IP54 2m
	Operating Temperature	-10℃~+50℃
	Storage Temperature	-20℃~+70℃
	Dimensions (H×W×D)	142mm×76mm×19mm
	Weight	210g
	Packing List	Q311×1, Strap, portable bag, data cable, manual

*Parameters of the latest version in 2024

▍Applications

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
