(MSS-R-T2391) Flagship Android Thermal Camera

Commodity name： (MSS-R-T2391) Flagship Android Thermal Camera

Category:

Email:

Description

Welcome to Shanghai Mengsheng Sheng International Trade

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

▍Explore the Ultimate Infrared World
Yaoguang T2391 is IRay's first 1280×1024 high-performance flagship infrared thermal camera. It is equipped with InfiRay® self-developed VOx infrared detector with thermal sensitivity as low as 25mK. It adopts MatrixⅣ intelligent image algorithm and AI-Temp accurate temperature measurement algorithm, providing clearer infrared images and higher precision of temperature measurement. Android operating system, intelligent applications & miscellaneous functions, and a 5.5-inch angle-adjustable display and rotatable handle bring a better experience meeting the ergonomics requirements.

▍Product Strengths
• Clear Thermal Images, Precise Temperature Measurement
• 1280×1024 infrared resolution, providing up to 2560×2048 high-definition super-resolution infrared thermal images
• Its thermal sensitivity can distinguish 0.025°C temperature difference, high temperature measurement precision, and can provide more-detailed thermal images
• Various Lenses and Precise Focusing
• Full coverage of lens focal lengths: 45°, 25°, 12° and 50μm, 25μm macro lenses to match more business applications
• Support multiple focusing methods such as manual focus, auto focus, laser focus, auto focus, and continuous auto-focusing.
• AI Empowerment fior Efficient Work
• Android system, more in line with users' habits and more convenient to operate
• Support up to 35 analysis area settings to analyze more temperature details
• 30Hz frame rate supports lossless compression of 16bit, meeting the needs of users for high frame rate and full-function secondary video analysis
• High-end Configuration, Easy to Work
• The classic shape of the SLR camera and the design of the fixed lens offer a better operational experience
• 5.5-inch flippable touch screen + OLED viewfinder of 1920 × 1080 for clearer field observation for users
• Support OTA upgrade, QC3.0/PD fast charging protocol
• Support Wi-Fi wireless screen mirroring and radiation video streaming and FTP/HTTP coverage of PCs and mobile devices

Yaoguang T2391 Lens Configuration Table
Lens type	FOV	IFOV	Focal Length	Minimum Imaging Distance	Aperture (F)
Long-focus Lens	12°×9.6°	0.17mrad	72.9mm	2.3m	1.0
Standard Lens	25°×20°	0.34mrad	34.9mm	0.5m	1.0
Wide-angle Lens	45°×36°	0.6mrad	19.8mm	0.2m	1.0
Macro Lens	0.2×	One pixel corresponds to 50μm	17.8mm	46mm	1.0
Super Macro Lens	0.4×	One pixel corresponds to 25μm	15.2mm	13mm	1.0
Manual＋autofocus lens, for automatic recognition once mounted

▍Specifications

Model		T2391 Standard Edition
Thermal Imaging Characteristics and Optical System	Detector Resolution	1280×1024
	Super Resolution	2560×2048
	Detector Type	Uncooled infrared detector
	NETD	25mK
	Wavelength Range	7.5~14µm
	Frame Rate	30Hz
	Focusing Mode	Manual, electric, laser-assisted, continuous auto focus
	Measurement Range	Standard: -20°C to +150°C (low temperature range), 150°C to 800°C (medium temperature range) Optional: 400°C to 1500°C\-40℃~+150℃
	Measurement Accuracy	±1°C or ±1% of the reading (whichever is the larger) for the measurement range of 5°C to 150°C at the ambient temperature of 25°C ±2°C or ±2% of the readings (whichever is the larger) for the measurement range below 1500°C at the ambient temperature of 25°C
Image Display and Mode	Display	5.5-inch sunlight-readable screen, 1920×1080 resolution
	Eyepiece	0.39-inch OLED display, 1920×1080 resolution
	Visible Light Camera	4224×3136 (13MP digital camera)
	Image Mode	Thermal imaging, PIP, thermal fusion, visible light
	Palettes	19 palettes including iron red, gray, inverse iron red, inverse gray
	Temperature Width Stretch	Automatic, manual, linear
Image Storage	Storage Medium	SD card, standard 64GB, hot plug, SD, SDHC, and SDXC supported, with a maximum extension capacity of 2TB
	Text Note	Yes. Free text input, preset text, OCR recognition, QR code scanning, and voice-to-text input supported
	Voice Note	Supported, with a maximum time length of 300s
Video Recording and Transmission	Radiation Infrared Video Recording	Support compressed full radiation video recording (.irv), up to 15Hz video recording
	Non-radiation Infrared or Visible Light Video	Standard .mp4 video recording
	Radiation Infrared Video Stream	TYPE-C/WLAN connection to PC, for real-time transmission of radiation infrared video streams
	Non-radiation Infrared Video Stream	RTSP H.264
	Communication Interface	USB3.0, Wi-Fi, MicroHDMI, Bluetooth
	Video Resolution	1920×1080
	Remote Access and Control	Support Type-C/Wi-Fi/hotspot, connection via the IRPT_TAS software on a PC and a mobile device (iOS/Android) for control; access to internal data in FTP mode
Measurement and Analysis	Alarm	Voice and image alarms
	Color Alarm (Isotherm)	Alarms above/below/between isotherms. Images displayed in palette mode within the isotherm range and in white-hot mode in other areas
	Positioning	Images+geolocation data. GPS, BDS, GLONASS, and BeiDou supported
	Compass	Azimuth indication of digital magnetic compass supported
	Analysis Report	PDF format. Template editing and import on the device
	Laser Rangefinding	620~690nm,Class II, <1mW; support laser pointer and laser rangefinding; rangefinding range 0.03-60m; accuracy±1mm+50PPM;
	Area Measurement	Supported
	Analysis Functions on the Device	Support up to 35 movable points, lines, frames, and polygonal areas, and up to 5 preset modes (maximum and minimum temperature capture, average temperature measurement, environment variables, area alarm switch)
	Temperature Difference Analysis	Supported
System Functions	Intelligent Routine Inspection	Supported. General task package import and editing, standard and automatic naming of images
	Routine Inspection Record Self-inspection	Supported
	Dual-Spectrum Video Recording	Simultaneous infrared video and visible light video recording, in MP4 format
	Zooming In	1‒15 times, continuously adjustable roller
	Connecting Methods	Wi-Fi, Bluetooth, USB Type-C, HDMI
	Voice Control	Voice assistant, quick command recognition
	Flashlight	Available
	Language	English, Japanese, Poland, Russian, Korean, Hungarian, Bap, German, French, Spain, Italy, Turkey, and Traditional Chinese
	Microphone/Speaker	Available
Others	Battery	4.2V, 9000mAh lithium-ion battery, field-replaceable, fast charging
	Charging Mode	Direct charging, desktop charging
	Operating Time	Continuous operating time ≥ 3 hours (depending on the actual environment and service conditions)
	External Interface	TYPE-C USB3.0, SD card, SIM card, Mini HDMI, tripod
	Operating Temperature	-15°C~+50°C
	Storage Temperature	-40°C~+70°C
	IP Grade	IP54
	Shock and Vibration	2G(IEC60068-2-6), 25G(IEC60068-2-29)
	Weight and Dimensions(H×W×D)	<1.7kg (with battery), 140mm×210mm×115mm
	Testing and Certification	CE/FCC/RoHS, etc.
	Packing List	T2391 infrared thermal imaging camera×1, manual, calibration certificate, quick operation guide, data download card, certificate, multi-country adapter (box), USB data cable×1, lithium-ion battery×3, portable bag, charging cradle (white)×1, HDMI cable×1, wriststrap, backpackstrap, SD card,charging stand, standard lens

▍Applications

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
