Physical Pixel

2.0MP

Sensor model

SONY CMOS IMX291sensor

Highest resolution

1920 x 1080 (2,073,600pixel)

Sensor size

1/2.8'' (6.058mm(H) x 4.415mm(V))

pixel size

2.9μm x 2.9μm

dynamic range

128dB

spectral response

380~650nm

exposure

Real time automatic, single time automatic, manual adjustment

white balance

Real time automatic, single time automatic and manual R G B adjustment respectively

FHD output resolution

1920X1080P60 maximum (adaptive according to the optional display)

Record format

Photograph Resolution: 1920x1080

Format: JPG

Videotape Resolution:maximum1920X1080P30,1280x720P60

Format:MOV

Record Path

TF card (up to 128G, hot plug)

power supply

DC 12V 3A

Working distance

44mm~169mm

Comprehensive magnification

8.9X~49.4X

Observation range

7mmx4mm~39mmx22mm

15.6"Screen parameters

Number of pixels

1920(horizontal) x 1080(vertical)

Pixel arrangement

RGB Vertical Bar

Number of colors displayed

16.7M(8Bit)

surface treatment

Anti-Glare

surface hardness

3H

Scope of view

Horizontal 85°, vertical 85°

contrast ratio

800

brightness

500cd/(5-point average )
