(MSS-M-OF011) Series Research Grade Upright Biological Microscope

Commodity name： (MSS-M-OF011) Series Research Grade Upright Biological Microscope

Category:

Email:

Description

Welcome to Shanghai Mengsheng Sheng International Trade

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

▍Description
Continuously exploring the research needs in the fields of pathology, cytology and virology, the OF011 research vertical microscope is constantly optimized and upgraded to possess nearly perfect optical performance and mechanical structure design. The NIS Infinite optical system has precise imaging and powerful chromatic aberration correction capabilities. This microscope features an illumination system with high color reproduction, high-quality optical elements and fully functional accessories, especially suitable for cutting-edge life science research requiring dark field, differential interference contrast or high-performance fluorescence. In addition, various motorized and intelligent components as well as powerful imaging software can meet the requirements of quickly viewing and detailedly examining samples, easily accomplishing repetitive work, greatly enhancing the simplicity of operation, increasing the operational comfort and maximizing the work efficiency. The OF011 can provide ideal microscopic imaging solutions for clinical laboratories and scientific research laboratories.

▍OF011 Series Research Upright Biological Microscope Specifications

Project		OF021	OF031	OF041	OF061
Microscope frame	Optical system	NIS infinite optical system
	Nosepieces	·Manual sextuple nosepiece	· Intelligent sextuple nosepiece	Motorized sextuple nosepiece	Motorized sextuple nosepiece
	Focusing	Low-hand coaxial focusing mechanism (with limit and elastic adjusting ring),focusing range is 35mm,and fine adjustment grid value is lum.			Low-hand motorized focusing mechanism,independent operation of left and right handwheels,three- speed adjustment,focusing range of 30mm,repetitive positioning accuracy of 0.1μm,motorized escape and recovery mechanism.
	Transmitted illumination	· 12V100W halogen lamp ·3WLED light source			3WLED,Transmitted source brightness motorized control,light intensity management function.
	Monitor		Microscope use status display screen		Touch control screen
Eyepiece tube	Binocular tube	Depression angle:30 degrees,pupillary distance adjustment range:47-78 mm.
	Trinoculartube	Eyepiece/port:100/0,20/80,0/100,depression angle:30 degrees,pupillary distance adjustment range:47-78 mm.
	Ergonomic trinoculartube	Eyepiece/port:100/0,20/80,0/100,depression angle:0-30 degrees,pupillary distance adjustment range:47-78 mm.
Eyepiece		·SW10X(25) ·SW10X (22) ·EW12.5X(17.5) ·WF15X(16) ·WF20X(12)
Stage	Manual stage (Corning glass countertop)	Moving distance:78(X)×32(Y)mm,1mm/grid,accuracy of 0.1mm,movable handle can be raised and lowered by 18mm,the tightness can be adjusted,and the bump guide mechanism is convenient,so it can be sliced with one hand.
	Manual stage (Sapphire glass countertop)
	Motorized stage				High-precision motorized XY stage (stroke:Xaxis,125mm;Y-axis, 75mm),and the repeated positioning accuracy is ±1.5μm.
Condensing lens	Brightfield condenser	Manual swing condenser	Manual swing condenser	motorized swing condenser	Universal condenser (4X-100X)
	Rotating disc condenser	·quintuple phase contrast turntable condenser.quintuple DIC turntable condenser ·Octagonal phase contrast DIC universal turntable condenser
	Darkfield condenser	·Darkfield condenser dry ·Darkfield condenser Oil
EL-900 Epi fluorescence illuminator	Epi-fluorescence illuminator	With field diaphragm and aperture diaphragm,density plate,kohlerillumination system and ultraviolet eye protection screen can be used.
	Filter cube turret	Sextuple epi-fluorescence cube turret (manual)
	Epi-illumination light source	·Osram mercury lamp HBO 100W/2 ·Metal halide light source 75W ·Four-color LED fluorescent 5W
FL-900C/D Epi- fluorescence illuminator	Epi-fluorescence illuminator	Recapture lighting with ultraviolet eye protection screen
	Filter cube turret	Sextuple epi-fluorescence cube turret (manual/motorized),up to four fluorescent lens groups can be installed.
	Epi-illumination light source	A
Observation method		Brightfield,Epi-fluorescence,darkfield,phase contrast,Simple polarizing,DIC

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
