Model

MSS-C-HF245HD MSS-C-HF245HN

Sensor

1/2" CMOS

Shutter

Global Shutter

Color/Mono

Color

Mono

Pixel Size

4.8X4.8μm

Resolution

1.3MP(1280X1024)

Frame Rate

1280X1024@91FPS

Pixel Bit Depth

10bit

Sensitivity

7.3 V/lux-s 540nm

I / O Port

1 way optical isolation input, one way optical isolation output; Optional 3 input 4 output

Synchronization

Continuous/soft trigger/continuous trigger

Maximum Gain

16.5

Exposure Time(ms)

0.008~1048

Filter

Standard 650nm Infrared Cut-off Filter

Standard double-sided AR-enhanced film

Frame Buffer

32M Bytes

Camera Custom Data

2K Bytes

Video Output Format

Bayer8/Bayer12

Mono8/Mono12

fisual Standard Protoco

GigE Vision V1.2、GenICam

Lens Mount

The default C interface, optional C or CS interface, can provide

M12 lens transfer intertace accessories

Data Interface

RJ45 Gigabit Ethernet interface, backward compatible with 100M network standard

Power Requirements

9-12V/POE48-57V(POE is optional)

Power Consumption

<2.5W

Dimensions

29(mm)X29(mm)X40(mm)

Weight

<75g

Working Temperature

0-50C

Working Humidity

20~80%( No Condensation )

Storage Temperature

-30-60C

Storage Humidity

20-95%(No Condensation )

Support System

WINXP WIN7 / 8/10 32 & 64-bit systems, Linux and ARM Linux drivers and Android platform drivers

(customizable)

Drivers

DirectShow components Halcon special components Labview dedicated drive OCX components IWAIN

components

Programming Language

C/C++/C#/VB6/VB.NET/Delphi/BCB/Python/Java

Programmable Control

lmage size (ROl), camera, exposure time, GAMMA, contrast, brightness, custom LUT, mirror flipRGB color gain, saturation, sharpness, color to mono, color temperature correction, anti-color,Colortrigger mode, frame rate control
